Allen & Heath ZED2842 28-CH 4-Bus Analog Mixer with USB Interface

Name: Allen & Heath ZED2842 28-CH 4-Bus Analog Mixer with USB Interface
Brand: Allen & Heath
Price: 8774.00 AED
Availability: InStock

Allen & Heath ZED2842 28-CH 4-Bus Analog Mixer with USB Interface

Based on 0 reviews. - Write a review

AED 8,774

Stock: In Stock
Model: ZED2842

Allen & Heath

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

The Allen & Heath 28-CH 4-Bus Analog Mixer with USB Interface ZED-428 is excellent for bands, houses of worship, theatres or AV applications. It has a truly professional feature set, which will fit any sound reinforcement application or professional PA hire stock. ZED-428 has configurable USB audio in/out, making it easy to capture stereo recordings, plus 24 mic/line inputs, 2 dual stereo inputs, 4-band EQ with MusiQ, 4 sub-groups, 6 auxiliary sends and a 7×2 matrix.

FEATURES

24 mono channels
2 dual stereo inputs with 4-band EQ
Neutrik mic XLR
Neutrik 1/4 inch jacks
Channel insert
Super wide gain ‘DuoPre’ mic line input
4-band EQ with 2 swept mids and in/out switch
Illuminated mute
Sound image pan
Illuminated PFL & peak warning indicator
ALPS 100mm faders
6 auxiliary sends (2 pre, 2 post, 2 pre/post)
4 sub groups fed from each channel
All inputs with level control
12 bar meters
L, R and M main mix outputs
2 matrix sections available; can send output to USB
Individual channel 48V phantom power
Direct output on every mono channel
Peak and signal indication on every channel
Configurable USB stereo audio in/out
Master level controls on all outputs
Easy to use layout – all connections and controls on top surface

Live Sound Mixers(Digital/ Analog/ Powered/ Line)
Type	Analog
Channels	24
Computer Connectivity	USB (2 x 2)
Faders	33 x 100mm
Inputs - Mic preamps	24 x XLR
Phantom Power	24
Inputs - Line	24 x 1/4" (CH 1-24), 4 x 1/4", 4 x RCA (CH 25-28 Stereo), 2 x RCA (2TRK)
Outputs - Main	2 x XLR (Main), 1 x XLR (Mono)
Outputs - Direct	32
Outputs - Others	2 x 1/4" (Matrix), 2 x RCA (2TRK), 4 x 1/4" (Group)
AUX Sends	2 x Pre, 2 x Post, 2 x Pre/Post
Busses / Groups	4 x Groups
Headphones	1 x 1/4", 1 x 1/8"
USB	1 x Type B
EQ Bands	4-band, Sweepable Hi- and Low-Mids (CH 1-24), 4-band (Stereo Channels)
Height	5.08"
Width	36.6"
Depth	22.1"
Weight	40 lbs.
Manufacturer Part Number	AH-ZED428
